Bilstein 33-247939 AS2 Series Modular Shock Absorber 5" Travel Linear Valving


Vendor: Bilstein

Part: 33-247939

Availability: Nationwide Backorder

Price: $259.00

This item is not available in the USA. You can pre-order and you will be notified when it is available. We will not charge your Credit Card until the items ordered are shipped. We will take an authorization when the order is processed, which may show as a Pending charge for 7 days. You will not lose your place in line. Thank You from Shockwarehouse.

Free Shipping for all order over $95
Payment methods
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

100% secure and protected payments

Dimensions:
Travel Length: 4.8 inches
Collapsed Length: 11 inches
Extended Length: 15.9 inches
Collapsed Length: 279.4mm
Extended Length: 403.9mm
Compression: Linear
Rebound: Linear

Bilstein AS2 Series of shock absorbers feature an all new modular design that allow this shock to be utilized in many different motorsport applications.

Features:
-46mm Threaded And Hard Anodized Monotube Shock Body
-Billet Aluminum End Cap
-Your Choice Of Either Linear Or Digressive Piston Designs
-Easy Disassembly And Reassembly For Fast Repairs Or Revalving
-1/2 Inch Heim Mounts
-Parts are Economically Priced And Available For Individual Purchase
-Valve Stacks and Valve Stacking Kits Available Separately for Endless Amounts of Setup Combinations
-Non Adjustable Hard Chrome Shafts Are Standard
-Single And Double Adjustable Shaft Assemblies Are Available As An Upgrade

Collapsed Length (IN) - 11
Extended Length (IN) - 15.9
Stroke (IN) - 4.9
Lower Mount Type - 1/2in Heim
Upper Mount Type - 1/2in Heim
Boot Included - No
Finish - Clear Anodized
Internal Design - Monotube

Dimensions:
Travel Length: 4.8 inches
Collapsed Length: 11 inches
Extended Length: 15.9 inches
Collapsed Length: 279.4mm
Extended Length: 403.9mm
Compression: Linear
Rebound: Linear

Bilstein AS2 Series of shock absorbers feature an all new modular design that allow this shock to be utilized in many different motorsport applications.

Features:
-46mm Threaded And Hard Anodized Monotube Shock Body
-Billet Aluminum End Cap
-Your Choice Of Either Linear Or Digressive Piston Designs
-Easy Disassembly And Reassembly For Fast Repairs Or Revalving
-1/2 Inch Heim Mounts
-Parts are Economically Priced And Available For Individual Purchase
-Valve Stacks and Valve Stacking Kits Available Separately for Endless Amounts of Setup Combinations
-Non Adjustable Hard Chrome Shafts Are Standard
-Single And Double Adjustable Shaft Assemblies Are Available As An Upgrade

Collapsed Length (IN) - 11
Extended Length (IN) - 15.9
Stroke (IN) - 4.9
Lower Mount Type - 1/2in Heim
Upper Mount Type - 1/2in Heim
Boot Included - No
Finish - Clear Anodized
Internal Design - Monotube
