Features & Benefits
The Bilstein Bumpstop improves suspension performance with more travel impact control and durability for offroad racing vehicles.To assist in smooth deceleration of suspension components for added control, this new bumpstop features a stronger mount design and a longer lasting contact pad for unequaled durability.
It also includes a larger fill valve thread design to eliminate valve failure.
Thick walled monotube design.
Fusion welded, seamless steel and electroless nickel finished body.
Universal frame bracket fitment (2-inch OD).
1 1/4 hardened chrome steel shaft.
Stronger 7075T6 aluminum contact pad.
Nitrogen adjustable spring rate capability.
Custom valved to your specifications.
Extended length: 13.2
Collapsed Length: 9.42
Travel: 4 "
Shaft diameter: 1.2
Collapsed Length (IN) - 9.61
Extended Length (IN) - 13.47
Stroke (IN) - 3.86
Lower Mount Type - Special
Upper Mount Type - Special
Boot Included - No
Finish - Electroless Nickel
Internal Design - Monotube
Body Design - 46mm ID Smooth Body (Non-Coilover) -
