FOX 981-20-040 Factory Race 2.0 X 2.0 Bump Stop Pinch Mount

FOX 2.0 Bumpstop 981-20-040

The FOX 2.0 Bumpstop 981-20-040 combines race-proven technology with cutting-edge features to improve damping performance and bottom-out control in the last few inches of suspension travel. Designed for high performance and durability, this bump stop is perfect for off-road enthusiasts seeking to maximize their vehicle's suspension capabilities.

Features of the 981-20-040:

• Threaded Impact Extruded Black Anodized CNC Machined 6061-T6 Billet Aluminum Body: Provides superior strength and durability while allowing for adjustable mounting height to fine-tune bump stop engagement.
• Replaceable Delrin® Strike Pad: Protects the bump stop and ensures longevity, even under extreme conditions.
• Hard Chrome Plated 1-1/4" 4130 Steel Shaft with Internal Floating Piston (IFP): Separates oil and nitrogen to prevent cavitation and bucking, enhancing damping performance.
• Heavy-Duty Powdered Steel Piston: Offers robust performance and durability in harsh conditions.
• Tunable Velocity Sensitive Deburred Valve Shims: Allow for precise tuning of the bump stop to suit specific performance needs.
• Redundant Sealing Pack System: Includes a main seal, wiper seal, and scraper seal to prevent leaks and ensure consistent performance.
• FOX AIR VALVE (FAV): Located at the bottom of the shaft for easy access, protected by the replaceable strike pad.
• Negative Coil Spring: Softens initial impacts and prevents harsh top-outs for a smoother ride.

Benefits of the 981-20-040:

• Increased Damping Performance: The advanced design and materials provide superior control and damping in the final stages of suspension travel.
• Adjustable Mounting Height: The threaded body allows for fine-tuning when the bump stop engages, preventing harsh bottom-outs.
• Prevention of Cavitation and Bucking: The Internal Floating Piston (IFP) ensures smooth and consistent performance by separating oil and nitrogen.
• Durability and Reliability: Built with high-quality materials and race-proven technology, this bump stop is designed to withstand the harshest off-road conditions.
• Maximized Suspension Travel: Allows for full use of suspension travel without harsh bottoming, enhancing overall performance and ride quality.

Specifications of the 981-20-040:

• Body Diameter (in): 2
• Body Material: Steel
• Bottom Mount: None
• Compressed Length (in): 7.70
• Extended Length (in): 9.74
• Reservoir Type: Emulsion
• Series: Factory Race
• Shaft Size (in): 1-1/4
• Top Mount: Pinch
• Travel (in): 2.04
• Type: Bump Stop
• Valving: 807-24-007

Upgrade your vehicle with the FOX 2.0 Bumpstop 981-20-040 and experience enhanced performance and control in your off-road adventures. This bump stop delivers the reliability and precision you need, perfect for those who demand the best from their suspension system.
