Features & Benefits
FOX External Bypass shocks have racked up countless wins across the globe over the past 30 years. There's no questioning whether they're race proven, but in the words of Bob Fox, "we're never done." In that spirit, we've reitalized our tried-and-true externally, adjustable position sensitive damping archtecture to deliver all-new standards of performance and durability, all while streamlining the production process.
Features
- NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat
- 17-4 H900 hard chrome plated stainless steel shaft
- Owner serviceable and rebuildable
- JM92 MIL-SPEC oil developed specifically for off-road racing
- Black Anodized CNC Machined Aluminum Components
Specifications
- Body Diameter (in): 3
- Body Material: Steel
- Bottom Mount: Eyelet
- Top Mount: Eyelet
- Bypass Tubes: 3
- Compressed Length (in): 16.6
- Extended Length (in): 24.46
- Mounting: 1/2 x 1-1/2
- Reservoir Dimensions: 2.55 x 8.00
- Reservoir Type: Remote
- Shaft Size (in): 7/8
- Travel (in): 7.86
- Type: External Bypass
- Eyelet Length (in): 2
- Valving: 807-24-600
- Seal Kit: 803-04-025
- Hose: -10 x 28.00
- Adjuster Type: External Bypass Clicker - Gen 2
- Body Finish: FOX Grey Cerakote
- Bypass Tube Size: 3/4
- Travel (rounded): 8
-
Fitments
-
