Features & Benefits
Designed to deliver a more comfortable ride, Monroe® air shocks and struts isolate impact-related noise, vibration and harshness. Leak and burst tested to ensure a reliable seal, they feature specially formulated air bellows for extended product life.
Specifications of the 40433:
- Active or Passive Suspension: Active
- Adjustable Compression: Yes
- Adjustable Rebound: Yes
- Adjustable Ride Height: Yes
- Air Fitting Style: Threaded
- Bladder Material: CR
- Compressed Length (IN): 30.12
- Compressed Length (MM): 765
- Cylinder Color: Black
- Cylinder Outside Diameter (IN): 1.97
- Cylinder Outside Diameter (MM): 50
- Dust Shield Diameter (IN): 4.92
- Dust Shield Diameter (MM): 125
- Dust Shield Included: Yes
- Dust Shield Material: Plastic
- Extended Length (IN): 35.43
- Extended Length (MM): 900
- Gas Charged: Gas
- Grade Type: Premium
- Includes Bump Stop: Yes
- Internal Construction Type: Single Tube
- Internal Rebound Bumper: No
- Internal Rebound Spring: No
- Lower Mount Type: Loop/Eyelet
- Maximum Air Chamber Pressure (PS): 101.5
- Mounting Hardware Included: Yes
- Shaft Diameter (IN): 0.55
- Shaft Diameter (MM): 14
- Suspension Type: Air
- Travel Length (IN): 5.31
- Travel Length (MM): 135
- Upper Mount Type: Stud
-
